Product Description
- The LOpSter Trap combines the function of electrical power “lunch boxes” with the data distribution of an “opto-splitter”, both of which are typically found in studios and on locations
- One box to inventory, transport, set up and strike as opposed to two
- Reliable DMX512/RDM Splitter/Repeater that processes communication protocols with a high degree of reliability
- 4.2A 4-Port USB Type-A Outlet Charger Receptacle for convenient powering of electronics
- Hydraulic magnetic breakers will not nuisance trip at higher temperatures and are mounted flush for easy access and circuit identification
- Brightly colored receptacles increase visibility in low-light situations
- Threaded inserts for brackets provide easy mounting of C-Clamps
- Pairing with the Lex PowerDataTM Cable greatly increases labor savings
Markets Served
Theatrical, Motion Picture, Television Production
| Rating: | 100 Amp, Single-phase (H,N,G), 2-pole, 3-wire, 125 VAC, 60 Hz |
|---|---|
| Environmental Rating: | NEMA Type 1 (Indoor Use) |
| Input: | (1) Stage Pin (Bates), 100 Amp, 2-pole, 3-wire, 125 VAC inlet, panel mount |
| Feed Thru: | Yes |
| Main Breaker: | None |
| Output: | (5) NEMA 5-20 (Edison), 20 Amp, 2-pole, 3-wire, 125 VAC, straight blade duplex receptacles, panel mount; (4) USB Type A, 4.2 Amp, 2-pole, 3-wire, 125 VAC 4-port receptacles, panel mount |
| Overcurrent Protection: | (5) 20 Amp, 125 VAC, single-pole, hydraulic magnetic, branch-rated circuit breakers |
| Data Input: | Wired 5-Pin XLR Inlet, DMX512/RDM |
| Data Feed Thru: | Yes |
| Data Output: | (5) Optically Isolated 5-Pin XLR Receptacles |
| Enclosure Type: | LOpSter™ |
| Dimensions: | 10.25”W x 11.50”H x 8.00”D |
| Weight: | 13.5 lbs |
